40-50 Ton Refrigeration Water Chiller
Construction Features Configuration
Environmentally Friendly R-404A Low Ambient Fan Cycling
Top Discharge Condenser Exhaust Low Ambient Flooded Condenser Includes Receiver with Isolation Valves (Optional)
Control Panel with Hinged Door Brazed Plate or Shell and Tube Evaporator
Insulated Copper Piping Condenser Ambient Fan cycle Control
G-90 Galvanized Cabinet Suction Line Filter-Dryer
Power Terminal Block with Single Point Electrical Connection Liquid Line Filter – Drier
Spring Mounted Compressors Thermal Expansion Valve
Digital Control Thermostat
Refrigerant & Electrical Safety Controls Suction and Liquid Vibration Eliminators
Low Water Flow Safety Shut-Off Dual or Single Copeland Discus Compressors
Short Cycling Time Delay Cylinder Unloading (Optional)
Low Refrigerant Pressure Control Compressor Staging For Dual Compressors (Optional)
High Refrigerant Pressure Control with Manual Re-Set Pump Down Solenoid
Freeze-Stat with Manual Re-Set Testing
Temperature Sensor Failure Protection UL/CUL Listed All Models
Compressor Crankcase Heater Leak Detection, Dielectric and Run Test
Control Circuit Fuses
Water Inline Strainer
